Drip lines with Mini PC Drippers

Highly resistant to UV and typical agricultural fertilizers

Vardit

Vardit is a compact, integral, pressure-compensated dripper designed for challenging topographies, water qualities, and soil conditions. This efficient and cost-effective PC dripline is the ideal choice for farmers focused on fast ROI and seeking a reliable, long-term drip irrigation solution.



Technical data:

Dripline diameters | 16/17/20/22/25 mm

Dripline wall thickness | 0.4/0.6/0.9/1.0/1.15/1.2 mm

Drippers spacing | 10/20/30/40/50/70/100/other cm

Dripper’s waterflow | 0.85/1.0/1.2/1.6/2.1/3.4 L/hr

Compensation range | 8-40 m



Applications | Open field | Orchards | Greenhouses | Landscaping

  • Higley accurate pressure-compensating self-flushing labyrinth mechanism
  • Wide range of working pressures for various topographies and crops
  • Highly resistant to UV and typical agricultural fertilizers
  • Very low CV
  • Wide self-cleaning labyrinth with turbulent flow to prevent particle settling
  • Driplines available at diameters of 16mm, 17mm, 20mm, 22mm,25mm
  • Precisely welded into medium/thick wall driplines of 0.40mm-1.25mm thickness
  • Available with Rootguard Band® extruded layer to prevent root intrusion in SDI applications

Calculate Vardit driplines running length

Dripper
Dripper Data
Dripline Data
?
Calculation Data
?
?
-4-3-2-101234
?
Define Lateral Length
More about ASSIF
Dripper
Dripper Data
Dripline Data
P (m)
?
Slope (%)
?
?
? Spacing (cm)
+ Add More
More about ASSIF
Non-Compensated Drippers
Dripper Data
Dripline
Dripline Data
More about ASSIF
Pipe Selection

* The C value is the recommended value for this pipe type. If another value is required, please type it in the input box.

Pipe Data
?
Legend
ΔZ (m)
– Elevation Difference (+ | -)
ΔP (m)
– Frictional Head Loss
ΔH (m)
– Total Head Loss (ΔZ + ΔP)
Q (m³/h)
– Flow Rate
Vmax. (m/s)
– Flow Velocity
L (m)
– Pipe Length
Pipe Type

* The C value is the recommended value for this pipe type. If another value is required, please type it in the input box..

Flow Rate
?
Pipe Selection
Pipe Data
?
?
Legend
ΔZ (m)
– Elevation Difference (+ | -)
ΔP (m)
– Frictional Head Loss
ΔH (m)
– Total Head Loss (ΔZ + ΔP)
Q (m³/h)
– Flow Rate
Vmax. (m/s)
– Flow Velocity
L (m)
– Pipe Length
