Dripline with Cylindrical Dripper

Turbulent labyrinth and clog-resistant

Idit

Idit is a robust cylindrical non-PC dripline, engineered for reliable irrigation across a wide variety of crops and water qualities. Its long turbulent labyrinth and clog-resistant inlet filter ensure uniform flow and durability, even under harsh field conditions. Suitable for orchards, row crops, and landscaping, IDIT offers a cost-effective solution that delivers performance growers can count on season after season.



Applications:  Open field | Orchards | Landscaping



Technical data:

Dripline diameters | 16 mm

Dripline wall thickness | 0.9/1.0/1.15/1.25 mm

Drippers spacing | 10/20/30/40/50/70/100/other cm

Dripper’s flow rates | 1.4/2.3/3.1/4.3/8/10 L/hr

  • Long Turbulent Labyrinth with Wide Water Passages
  • Highly resistant to UV and typical agricultural fertilizers
  • Highly clog-resistant cylindrical inlet filter – ensures clean and continuous flow
  • Color striping available per grower’s choice
  • Excellent for effluent reused water
  • Very low CV
  • 100% of drippers are inspected by on-line AI quality assurance system
  • Available with Rootguard Band® extruded layer to prevent root intrusion in SDI application

Calculate Idit driplines running length

Dripper
Dripper Data
Dripline Data
?
Calculation Data
?
?
-4-3-2-101234
?
Define Lateral Length
More about ASSIF
Dripper
Dripper Data
Dripline Data
P (m)
?
Slope (%)
?
?
? Spacing (cm)
+ Add More
More about ASSIF
Non-Compensated Drippers
Dripper Data
Dripline
Dripline Data
More about ASSIF
Pipe Selection

* The C value is the recommended value for this pipe type. If another value is required, please type it in the input box.

Pipe Data
?
Legend
ΔZ (m)
– Elevation Difference (+ | -)
ΔP (m)
– Frictional Head Loss
ΔH (m)
– Total Head Loss (ΔZ + ΔP)
Q (m³/h)
– Flow Rate
Vmax. (m/s)
– Flow Velocity
L (m)
– Pipe Length
Pipe Type

* The C value is the recommended value for this pipe type. If another value is required, please type it in the input box..

Flow Rate
?
Pipe Selection
Pipe Data
?
?
Legend
ΔZ (m)
– Elevation Difference (+ | -)
ΔP (m)
– Frictional Head Loss
ΔH (m)
– Total Head Loss (ΔZ + ΔP)
Q (m³/h)
– Flow Rate
Vmax. (m/s)
– Flow Velocity
L (m)
– Pipe Length
